Rubberworx™ PVC Water Suction hoses to meet the most rigorous applications for industrial water transfer. Rubber, Textile, and PVC constructions that will meet your requirements for weight, durability, or flexibility.
Menu
Rubberworx™ PVC Water Suction hoses to meet the most rigorous applications for industrial water transfer. Rubber, Textile, and PVC constructions that will meet your requirements for weight, durability, or flexibility.
|
Category
|
Part Number
|
ID (in)
|
OD (in)
|
Tube Thickness
|
Pressure (psi)
|
Burst Ration (safety factor)
|
Vacuum Rating
|
Bend Radius
|
Braid Coverage
|
Pitch (in)
|
Weight (oz/yd)
|
Length (ft)
| Reset filters | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1001206 | 1001206-1000 | 10 | 10.86 | NA | 40 | 3:1 | 28 | 25 | 1001206-1000 |
| ||||||
| 1001206 | 1001206-1200 | 12 | 13.9 | NA | 28 | 3:1 | 28 | 45 | 1001206-1200 |
| ||||||
| 1001206 | 1001206-150 | 1.5 | 1.95 | NA | 100 | 3:1 | 28 | 3 | 1001206-150 |
| ||||||
| 1001206 | 1001206-200 | 2 | 2.6 | NA | 100 | 3:1 | 28 | 4 | 1001206-200 |
| ||||||
| 1001206 | 1001206-300 | 3 | 3.62 | NA | 100 | 3:1 | 28 | 6 | 1001206-300 |
| ||||||
| 1001206 | 1001206-400 | 4 | 4.8 | NA | 75 | 3:1 | 28 | 7 | NA | NA | NA | NA | 1001206-400 |
| ||
| 1001206 | 1001206-500 | 5 | 6.05 | NA | 70 | 3:1 | 28 | 9 | NA | NA | NA | NA | 1001206-500 |
| ||
| 1001206 | 1001206-600 | 6 | 7.17 | NA | 70 | 3:1 | 28 | 10 | NA | NA | NA | NA | 1001206-600 |
| ||
| 1001206 | 1001206-800 | 8 | 9.34 | NA | 70 | 3:1 | 28 | 16 | NA | NA | NA | NA | 1001206-800 |
| ||
| 1002106 | 1002106-075 | 0.75 | 1.02 | NA | 100 | 3:1 | 28 | 2 | NA | NA | NA | NA | 1002106-075 |
| ||
| 1002106 | 1002106-100 | 1 | 1.29 | NA | 100 | 3:1 | 28 | 3 | NA | NA | NA | NA | 1002106-100 |
| ||
| 1002106 | 1002106-1000 | 10 | 11.34 | NA | 40 | 3:1 | 28 | 40 | NA | NA | NA | NA | 1002106-1000 |
| ||
| 1002106 | 1002106-1200 | 12 | 13.19 | NA | 35 | 3:1 | 28 | 50 | NA | NA | NA | NA | 1002106-1200 |
| ||
| 1002106 | 1002106-125 | 1.25 | 1.56 | NA | 90 | 3:1 | 28 | 4 | NA | NA | NA | NA | 1002106-125 |
| ||
| 1002106 | 1002106-150 | 1.5 | 1.84 | NA | 90 | 3:1 | 28 | 4 | NA | NA | NA | NA | 1002106-150 |
| ||
| 1002106 | 1002106-200 | 2 | 2.39 | NA | 70 | 3:1 | 28 | 5 | NA | NA | NA | NA | 1002106-200 |
| ||
| 1002106 | 1002106-200 | 2.5 | 2.92 | NA | 65 | 3:1 | 28 | 7 | NA | NA | NA | NA | 1002106-200 |
| ||
| 1002106 | 1002106-300 | 3 | 3.46 | NA | 55 | 3:1 | 28 | 8 | NA | NA | NA | NA | 1002106-300 |
| ||
| 1002106 | 1002106-400 | 4 | 4.56 | NA | 50 | 3:1 | 28 | 12 | NA | NA | NA | NA | 1002106-400 |
| ||
| 1002106 | 1002106-500 | 5 | 5.65 | NA | 45 | 3:1 | 28 | 20 | NA | NA | NA | NA | 1002106-500 |
| ||
| 1002106 | 1002106-600 | 6 | 6.8 | NA | 45 | 3:1 | 28 | 23 | NA | NA | NA | NA | 1002106-600 |
| ||
| 1002106 | 1002106-800 | 8 | 8.95 | NA | 40 | 3:1 | 28 | 34 | NA | NA | NA | NA | 1002106-800 |
| ||
| 1006106 | 1006106-075 | 0.75 | 1.02 | NA | 100 | 3:1 | 28 | 2 | NA | NA | NA | NA | 1006106-075 |
| ||
| 1006106 | 1006106-100 | 1 | 1.29 | NA | 100 | 3:1 | 28 | 3 | NA | NA | NA | NA | 1006106-100 |
| ||
| 1006106 | 1006106-1000 | 10 | 11.34 | NA | 40 | 3:1 | 28 | 40 | NA | NA | NA | NA | 1006106-1000 |
| ||
| 1006106 | 1006106-1200 | 12 | 13.19 | NA | 35 | 3:1 | 28 | 50 | NA | NA | NA | NA | 1006106-1200 |
| ||
| 1006106 | 1006106-125 | 1.25 | 1.56 | NA | 90 | 3:1 | 28 | 4 | NA | NA | NA | NA | 1006106-125 |
| ||
| 1006106 | 1006106-150 | 1.5 | 1.84 | NA | 90 | 3:1 | 28 | 4 | NA | NA | NA | NA | 1006106-150 |
| ||
| 1006106 | 1006106-200 | 2 | 2.39 | NA | 70 | 3:1 | 28 | 5 | NA | NA | NA | NA | 1006106-200 |
| ||
| 1006106 | 1006106-200 | 2.5 | 2.92 | NA | 65 | 3:1 | 28 | 7 | NA | NA | NA | NA | 1006106-200 |
| ||
| 1006106 | 1006106-300 | 3 | 3.46 | NA | 55 | 3:1 | 28 | 8 | NA | NA | NA | NA | 1006106-300 |
| ||
| 1006106 | 1006106-400 | 4 | 4.56 | NA | 50 | 3:1 | 28 | 12 | NA | NA | NA | NA | 1006106-400 |
| ||
| 1006106 | 1006106-500 | 5 | 5.65 | NA | 45 | 3:1 | 28 | 20 | NA | NA | NA | NA | 1006106-500 |
| ||
| 1006106 | 1006106-600 | 6 | 6.8 | NA | 45 | 3:1 | 28 | 23 | NA | NA | NA | NA | 1006106-600 |
| ||
| 1006106 | 1006106-800 | 8 | 8.95 | NA | 40 | 3:1 | 28 | 34 | NA | NA | NA | NA | 1006106-800 |
| ||
| 1024106 | 1024106-100 | 1 | 1.25 | NA | 65 | 3:1 | 28 | 3 | NA | NA | NA | NA | 1024106-100 |
| ||
| 1024106 | 1024106-125 | 1.25 | 1.56 | NA | 65 | 3:1 | 28 | 4 | NA | NA | NA | NA | 1024106-125 |
| ||
| 1024106 | 1024106-150 | 1.5 | 1.77 | NA | 65 | 3:1 | 28 | 5 | NA | NA | NA | NA | 1024106-150 |
| ||
| 1024106 | 1024106-200 | 2 | 2.36 | NA | 65 | 3:1 | 28 | 7 | NA | NA | NA | NA | 1024106-200 |
| ||
| 1024106 | 1024106-200 | 2.5 | 2.9 | NA | 50 | 3:1 | 28 | 8 | NA | NA | NA | NA | 1024106-200 |
| ||
| 1024106 | 1024106-300 | 3 | 3.42 | NA | 5 | 3:1 | 28 | 10 | NA | NA | NA | NA | 1024106-300 |
| ||
| 1024106 | 1024106-400 | 4 | 4.5 | NA | 40 | 3:1 | 28 | 15 | NA | NA | NA | NA | 1024106-400 |
| ||
| 1024106 | 1024106-500 | 5 | 5.59 | NA | 30 | 3:1 | 28 | 25 | NA | NA | NA | NA | 1024106-500 |
| ||
| 1024106 | 1024106-600 | 6 | 6.7 | NA | 25 | 3:1 | 28 | 30 | NA | NA | NA | NA | 1024106-600 |
|
