RM140W Overfill Protection Rack Monitor

Overfill protection and grounding monitor for truck or rail loading in petrochemical applications. Built to function with all probes designed to the API code: API RP 1004 and the EU Standard EN13922, the RM140W Series is the world’s most flexible and adaptable monitor.

The RM140W provides a fail-safe, state-of-the-art overfill protection, and grounding monitoring system that is compatible with all commonly used overfill protection and grounding systems.

Features/Benefits

Specifications

Electrical

Power	240V Operation	110V Operation
Minimum Input Voltage	185VAC	85VAC
Maximum Input Voltage	275VAC	135VAC
In-rush Current	2.2A	2.3A
Maximum Current	400mA	400mA
Normal Power Consumption	8.6W (No probe) 20W (8x 2-wire probes)	8.6W (No probe) 20W (8x 2-wire probes)
Mains Power Fuse Rating	250V, 400mA anti-surge 1500A Breaking Capacity	250V 400mA anti-surge 1500A Breaking Capacity

Showing 1 to 6 of 6 entries

Intrinsically Safe Signals

Nominal Voltage	10.5V, 13.02V Max
Nominal Current	116mA, 121mA Max
Relay Outputs	Overfill Monitoring Relay
Relay Contacts	Common, Normally Open, Normally Closed
Maximum Contact Voltage	250VAC
Maximum Contact Load	5A (resistive), 2.5A (inductive)
Relay Fuse Rating	250V @ 5A anti-surge

Mechanical

	Standard	Metric
Width	12.8″	324mm
Height	13.4″	340mm
Depth	13.4″	170mm
Weight	36.37 lb	16.5 kg
Material	Aluminium Housing Base and Cover, Laminated Glass Window
